Bevestigingsprofiel voor 4 kabels 13-32mm (horizontaal)
suitable for fastening multiple cables with one or more low-, medium- or high-voltage conductors, side by side or in multiple layers
material: glass-fiber reinforced polyamide, bending strength 210 N/mm², tensile strength 120 N/mm²
resistant to UV rays, salt water, ozone, oils and alkalis
self-extinguishing to UL94-V-0 and DIN 5510-2:2009
coefficient of thermal expansion: +0.01%/+10°C
temperature range: -50°C to +120°C stable, +220°C peak
stainless steel fasteners suitable for almost any assembly are available on request
halogen-free
material: glass-fiber reinforced polyamide, bending strength 210 N/mm², tensile strength 120 N/mm²
resistant to UV rays, salt water, ozone, oils and alkalis
self-extinguishing to UL94-V-0 and DIN 5510-2:2009
coefficient of thermal expansion: +0.01%/+10°C
temperature range: -50°C to +120°C stable, +220°C peak
stainless steel fasteners suitable for almost any assembly are available on request
halogen-free
| D: 10.5 mm |
| H: 45 mm |
| Cable: 13-32 mm |
| E: 60.5 mm |
| G: 43 mm |
