Cont. f. Capac. 20kVAr 3~400V 380-415V 50Hz 415-440V 60Hz
U(max) : 690 Vac
designed to switch low-induction and low-loss capacitor banks with or without reactors
equipped with advanced contacts and resistors that limit peak current to < 70 x I(e)
in the table:
P(r) XX YYY = Nominal reactive power at XX °C in YYY V AC
ex: P(r) 50 400 = Rated reactive power at 50°C in 400V AC
designed to switch low-induction and low-loss capacitor banks with or without reactors
equipped with advanced contacts and resistors that limit peak current to < 70 x I(e)
in the table:
P(r) XX YYY = Nominal reactive power at XX °C in YYY V AC
ex: P(r) 50 400 = Rated reactive power at 50°C in 400V AC
| U(n) coil: 400 Vac |
| Attachable auxiliary contacts: 2 HB... + 1 HN.../HA... |
| P(r)50 400kVAr: 10-20 |
| P(r)50 440kVAr: 10.5-22 |
| P(r)50 690kVAr: 17-33 |
| P(r)60 400kVAr: 10-20 |
| P(r)60 440kVAr: 10.5-22 |
| P(r)60 690kVAr: 17-33 |
