Kondensatorbatterieschütz 100kVar 3~400V 230Vac
U(max) : 690 Vac
designed to switch low-induction and low-loss capacitor banks with or without reactors
equipped with advanced contacts and resistors that limit peak current to < 70 x I(e)
in the table:
P(r) XX YYY = Nominal reactive power at XX °C in YYY V AC
ex: P(r) 50 400 = Rated reactive power at 50°C in 400V AC
designed to switch low-induction and low-loss capacitor banks with or without reactors
equipped with advanced contacts and resistors that limit peak current to < 70 x I(e)
in the table:
P(r) XX YYY = Nominal reactive power at XX °C in YYY V AC
ex: P(r) 50 400 = Rated reactive power at 50°C in 400V AC
| U(n) coil: 230 Vac |
| Attachable auxiliary contacts: 2 HB... + 4 HN.../HA... |
| P(r)50 400kVAr: 33-100 |
| P(r)50 440kVAr: 36-103 |
| P(r)50 690kVAr: 57-148 |
| P(r)60 400kVAr: 33-90 |
| P(r)60 440kVAr: 36-93 |
| P(r)60 690kVAr: 57-148 |
